DETAIL Description of the Product
| Product Series |
Rated Speed(RPM) | Rated Output(kW) | Rated Voltage(V) | Rated Current(A) | Rated Torque(N-m) | Rated Torque(Kg-m) | Rotor Inertial(Kg-m²) | Max. Speed(RPM) | Frame Size |
| SVMJ IP23 | 1000 | 110 | 380 | 204.4 | 1050 | 107.1 | 1.479 | 4500 | SA-225S |
| SVMJ IP23 | 1500 | 150 | 380 | 278.7 | 954 | 97.35 | 1.479 | 4500 | SA-225S |
| SVMJ IP23 | 2000 | 175 | 380 | 325.1 | 834 | 85.1 | 1.479 | 4500 | SA-225S |
