DETAIL Description of the Product
| Product Series |
Rated Speed(RPM) | Rated Output(kW) | Rated Voltage(V) | Rated Current(A) | Rated Torque(N-m) | Rated Torque(Kg-m) | Rotor Inertial(Kg-m²) | Max. Speed(RPM) | Frame Size |
| SVMF IP54 | 500 | 18.5 | 360 | 42 | 350.2 | 36 | 0.5463 | 3500 | SF-180P |
| SVMF IP54 | 1000 | 37 | 360 | 79.8 | 350.2 | 36 | 0.5463 | 3500 | SF-180P |
| SVMF IP54 | 1500 | 55 | 380 | 115 | 348 | 35.8 | 0.5463 | 3000 | SF-180P |
