Product Series |
Rated Speed(RPM) | Rated Output(kW) | Rated Voltage(V) | Rated Current(A) | Rated Torque(N-m) | Rated Torque(Kg-m) | Rotor Inertial(Kg-m²) | Max. Speed(RPM) | Frame Size |
SVMF IP23 | 500 | 15 | 360 | 35 | 283.9 | 29.2 | 0.0685 | 6000 | SA-132L |
SVMF IP23 | 1000 | 30 | 360 | 64.9 | 284.2 | 29.2 | 0.0685 | 6000 | SA-132L |
SVMF IP23 | 1500 | 37 | 380 | 75.7 | 234.2 | 24.1 | 0.0685 | 6000 | SA-132L |
SVMF IP23 | 900/1800 | 22 | 380 | 44.5 | 208 | 21.4 | 0.0685 | 6000 | SA-132L |
