DETAIL 商品详细说明
| Product Series |
Rated Speed(RPM) | Rated Output(kW) | Rated Voltage(V) | Rated Current(A) | Rated Torque(N-m) | Rated Torque(Kg-m) | Rotor Inertial(Kg-m²) | Max. Speed(RPM) | Frame Size |
| SVMF IP23 | 500 | 165 | 360 | 334 | 3126 | 321.6 | 7.4323 | 3000 | SA-280L |
| SVMF IP23 | 1000 | 350 | 360 | 688 | 3315 | 341.1 | 7.4323 | 3000 | SA-280L |
| SVMF IP23 | 1500 | 500 | 380 | 994 | 3150 | 324.1 | 7.4323 | 3000 | SA-280L |
| SVMF IP23 | 900/1800 | 315 | 360 | 641 | 3312 | 340.8 | 7.4323 | 3000 | SA-280L |
| SVMF IP23 | 600/1800 | 195 | 360 | 373 | 3078 | 316.7 | 7.4323 | 3000 | SA-280L |
| SVMF IP23 | 500/2000 | 150 | 360 | 347 | 2839 | 292.1 | 7.4323 | 3000 | SA-280L |
