DETAIL 商品详细说明
| Product Series |
Rated Speed(RPM) | Rated Output(kW) | Rated Voltage(V) | Rated Current(A) | Rated Torque(N-m) | Rated Torque(Kg-m) | Rotor Inertial(Kg-m²) | Max. Speed(RPM) | Frame Size |
| SVMF IP23 | 500 | 84 | 360 | 180 | 1590 | 163.6 | 2.6569 | 3000 | SA-225L |
| SVMF IP23 | 1000 | 167 | 360 | 330.7 | 1580 | 162.6 | 2.6569 | 3000 | SA-225L |
| SVMF IP23 | 1500 | 220 | 380 | 434.4 | 1389 | 142.9 | 2.6569 | 3000 | SA-225L |
| SVMF IP23 | 900/1800 | 130 | 360 | 262 | 1367 | 140.6 | 2.6569 | 3000 | SA-225L |
| SVMF IP23 | 600/1800 | 90 | 360 | 183 | 1420 | 146.1 | 2.6569 | 3000 | SA-225L |
| SVMF IP23 | 500/2000 | 75 | 360 | 197 | 1420 | 146.1 | 2.6569 | 3000 | SA-225L |
